Infrastructure
World class modern infra to produce Global quality castings.
- Premises
- Pattern shop
- Core shop
- Melting
- Fettling
- Quality Lab
Premises
Foundry Premises
Machine Shop Premises
Machine Shop Premises
- Total Land Area: 30,000 Sq Meters
- Foundry Office Area: 1000 Sq Meters
- Foundry Work Area: 15000 Sq Meters
- Machine Shop Office Area: 1000 Sq Meters
- Machine Shop Work Area: 3000 Sq meters
- A full fledged office with dedicated departments for Marketing, Sales , Finance & Accounts, Purchase, Production, Quality, and Logistics.
Pattern shop
- Tooling Development is supported with CAD / CAM & AUTOCAST - Simulation Software facilities which minimizes the development time .
- We are capable of submitting all parts with APQP, FMEA, CONTROL PLAN, SPC,MSA,PSW,PPAP.
- In house facility for undertaking the Mounting of patterns followed by methoding and rework wherever required.
- Two numbers of Lathes, one Milling machine, one Cutting machine, Surface table, Height gauge, and Digital Vernier exclusively for handling pattern shop activities
- Coordinate Measuring Machine (CMM ) to inspect the First sample dimensions whenever required
Core shop
- A Shell Core Shooter of 5Kg capacity
- 3 Nos of Cold Box Core Shooter of 5Kgs, 10Kgs and 15 Kgs capacity
- Co2 Core making facility with 8 tables
- Heating Oven for baking of cores
- 2 nos x 250kgs Core Sand Mixer
- 2 Ton/hour capacity Core Sand Drier
Melting
- 2 Nos of Medium Frequency Induction Furnace with 600 KW capacity each of Inductotherm make
- Each of the above furnace has 2 Nos of 1 Ton Crucible
- 3 Ton EOT Crane with 250Kgs and 500Kgs Treatment ladles
- Mono Rail system for Pouring
- 4 Nos of 500 Kgs Ladles for magnesium treatment for Ductile Iron
- 12 numbers of SOHGS Hand Shanks.
- Dust collector facility for environmental protection
Fettling
- Hydraulic wedge cutting machine for breaking runner and riser
- Two numbers of 500 Kgs capacity shot blasting machine.
- 8 numbers of Bench grinders and 2 Nos of Swing frame grinders supported by combination of pneumatic grinders.
- Trimming Machine of 60 Tons capacity
- Tumble blasting machine of 300 Kg Capacity for cleaning of components
- Nozzle Blasting machine to clean intricate and complex core holes
Testing facilities
- Spectrometer: ARL (Swiss) make 29 element analyzer
- Image Analyzer with Camera Attached to Microscope
- Sand Testing Equipments
- Tensile & Hardness Tester
- CEE Meter
- Charpy impact tester
Automobile Part
Manifold Pipe
Railway Insert
Axle Box Housing
Brake Drum
Magnetic Frame
Breaker Oil Tank
Coolant Pipe
Ring Casting
Connection Water Inlet
Gear Case
Pressure Bowl
Jewellery Ring
